2009 Swissbike TX
Archive
This is an archived page of a previous model year bike. This bike is no longer in production with these specifications.
The Essentials
• Speeds: 21
• Wheel Size: 26″
• Folding Time: 20 sec.
• Folded Size: 36″x28″x12″
• Approx Weight: 30lbs
Great For
• Exploring the city.
• Weekend camping trips.
• Getting to work on time.
Bike Sizing
Standover height is 30″
• 20in Frame: For riders 5’11” – 6’4″.
Standover height is 31″
Description
Gallery
CLIX Folding System
Folding Integrated Technology
The SwissBike TX frame is designed around a patented folding system. This design eliminates the need to break the frame in order to fold the bike. Not only does this make folding easier but it makes this bike the strongest folding bike on the market. The Folding Integrated Technology (F.I.T.) is based around frame construction concepts designed for serious full suspension downhill bikes.
Dual-Sport Versatility
We like to call the SwissBike TX a dual-sport. While it still has the front-suspension and disc brakes found on some of our true mountain bikes, the TX comes equipped with a semi-slick tire that effectively bridges the gap between road and mountain. The smooth, but wide nature of the TX tires allow it to flow easily through the streets, while still taking off road detours.
2009 Specifications
| Specifications | |
| Color | Silver |
| Frame | Custom drawn 7005 Series Aluminum with FIT System. Power Angle geometry. Double top tube. |
| Fork | SR Suntour SF-9 Suspension with 65mm Travel, Rebound Adjust and disc mount. |
| Rims | Jalco Alloy, 32 hole, Double Wall w/CNC Side wall, Black |
| Tires | 26 x 1.5” Kenda Kwest Slick. Steel bead clincher front and rear |
| Hubset | Formula black, Alloy sealed front & rear with CLIX™ front release |
| Spokes | 14G stainless |
| Saddle | Cionlli, Black with comfort groove |
| Seatpost | Micro Adjust |
| Handlebars | Matt Black, 30mm rise |
| Stem | Alloy Direct Connect 105mm, 15 degree rise |
| Shifters | Sram, MRX Twist Shift |
| Front Derailleur | Shimano Compatible Top Pull |
| Rear Derailleur | Shimano TX-50 Tourney 7-speed |
| Crankset | SR Suntour, Alloy, 42-34-22, 170mm |
| Speeds | 21 Speeds |
| Brakeset | Front: Promax Disc with dual pad adjustment. Rear, Alloy V-Style, with alloy levers |
| Pedals | Bear Trap |
| Bottom Bracket | Sealed Cartridge |
| Frame Sizes | 18”, 20” |
| Stand over heights | 29”, 30” |
| Folded Size | 36” x 28” x 12” |
| Approx Weight | Sealed Cartridge |
| MSRP | $699.00 |
| Specifications and prices subject to change without notice. Bike specifications and prices for your country may differ. We do our best to ensure that the listed specifications accurately reflect the parts found on our folding bikes. Even so, we may have to change the component specifications from time to time. We do our best to make sure that all component substitutions are of equal performance and cosmetics as those listed . Also our international distributors often ask us to modify components to better suit their local markets. Please contact your local distributor for information about bikes in your area. | |
